一、进口气体增压泵概述

威盾VTON的VDBA 系列气体增压泵，Gas booster pump，利用大面积活塞端的低压气体驱动而产生小面积活塞端的高压流体。可用于压缩空气及其它气体，输出气压可通过驱动气压无级调节。采用单气控非平衡气体分配阀来实现泵的往复运动，全部采用铝合金及不锈钢制造且密封件均为进口产品，主要应用于在输出气压高但流量要求不太高的应用场合。 泵型均可定制，参数定制，材质定制。

VDBA series gas booster pump from Weidun VTON, Gas booster pump， Using low-pressure gas from the large-area piston end to drive and generate high-pressure fluid from the large-area piston end. It can be used to compress air and other gases, and the output pressure can be infinitely adjusted by driving the pressure. Adopting a single gas controlled non-equilibrium gas distribution valve to achieve reciprocating motion of the pump, all made of aluminum alloy and stainless steel with imported seals, mainly used in applications with high output pressure but low flow requirements. Pump types can be customized, parameters can be customized, and materials can be customized.

二、进口气体增压泵产品特点

1、专门设计的换向阀与泵体装配在一起，自动换向。

2、驱动缸、缸盖采用铝合金型材加工，材质致密，避免微裂纹压力损失，外形整洁美观。

3、作用缸筒采用满吸设计，并采用高质量不锈钢整体淬火精密加工，长期工作磨损小，无变形，无渗漏。

4、泵的进出口单向阀采用与作用缸不同材质的不锈钢精密加工，保压可靠。

5、专用的换向阀确保驱动换向、相同气压下泵动作频次高，可靠性高。

6、整套机构摩擦力矩低，压力损失小，极低启动气压，确保增压迅速，泵运行稳定，效率高，噪声低。

1. Specially designed directional valve is assembled with the pump body to automatically change direction.

2. The drive cylinder and cylinder head are processed with aluminum alloy profiles, which are dense in material, avoiding micro crack pressure loss, and have a clean and beautiful appearance.

3. The action cylinder adopts a full suction design and is precision machined with high-quality stainless steel quenching. It has low long-term wear, no deformation, and no leakage.

4. The inlet and outlet check valves of the pump are made of stainless steel precision machined from a material different from that of the action cylinder, ensuring reliable pressure maintenance.

5. The dedicated directional valve ensures high frequency and reliability of pump operation under the same pressure and driving direction.

6. The entire mechanism has low friction torque, minimal pressure loss, extremely low starting air pressure, ensuring rapid pressurization, stable pump operation, high efficiency, and low noise.

三、进口气体增压泵应用范围

1、压缩空气增压

2、航空航天附件维修后的静态、动态测试

3、气体压缩存储

4、气压调节器的检测

5、压力气密性检测

6、稀有气体回收

7、飞机轮胎和液压蓄能器充氮气

8、气体辅助注塑中高压氮气充气，超纯气体的压缩(二氧化碳超临萃取)

9、可增压氮气，氢气，空气，二氧化碳，氦气，臭氧，甲烷等各种气体

1. Compressed air pressurization

2. Static and dynamic testing of aerospace accessories after maintenance

3. Gas compression storage

4. Testing of air pressure regulator

5. Pressure and airtightness testing

6. Rare gas recovery

7. Aircraft tires and hydraulic accumulator filled with nitrogen gas

8. High pressure nitrogen inflation in gas assisted injection molding, compression of ultra pure gas (carbon dioxide super extraction)

9. Can be pressurized with various gases such as nitrogen, hydrogen, air, carbon dioxide, helium, ozone, methane, etc
