一、进口氟利昂增压泵概述

威盾VTON的氟利昂增压泵，Freon booster pump，系列采用单气控非平衡气体分配阀来实现泵的往复运动，全部采用铝合金及不锈钢制造。全部密封均为进口优质产品，zui大设计驱动气压均为10bar，为了保证泵的寿命建议驱动气压<8bar。该系列泵的驱动活塞直径为160mm，为单作用泵，所有单作用泵均带有排气冷却。

采用普通工厂压缩空气增压泵作为驱动动力，用于增压氟利昂或其他冷媒。用了耐制冷剂/冷媒介质的密封圈，广泛用于制冷剂/氟利昂回收、制冷剂/氟利昂重装等行业。压力无级可调，保压不消耗能量。制冷剂增压泵/氟利昂增压泵的重量轻，便于携带，整机重量在18KG左右。

Weidun VTON's Freon booster pump, Freon booster pump， The series adopts a single gas controlled non-equilibrium gas distribution valve to achieve the reciprocating motion of the pump, all of which are made of aluminum alloy and stainless steel. All seals are imported high-quality products, and the maximum designed driving pressure is 10 bar. To ensure the service life of the pump, it is recommended that the driving pressure be less than 8 bar. The drive piston diameter of this series of pumps is 160mm, which is a single acting pump. All single acting pumps are equipped with exhaust cooling.

Using a regular factory compressed air booster pump as the driving force for boosting Freon or other refrigerants. Sealing rings that are resistant to refrigerants/refrigerant media are widely used in industries such as refrigerant/Freon recovery and refrigerant/Freon reinstallation. Pressure is infinitely adjustable, maintaining pressure without consuming energy. The refrigerant booster pump/Freon booster pump is lightweight and easy to carry, with a total weight of around 18KG.

二、进口氟利昂增压泵应用范围

1、适应于R22、R134a、R407C、R410A等各种冷媒的输送

2、该装置用于制冷行业生产中需要较远距离输送的冷媒中央输送增压站

3、可节省生产线上冷媒搬运、换储气罐环节，节约人力，减少冷媒浪费

4、全气动运行，无需电源

5、全自动工作，节省人力

6、制冷行业：制冷剂填充量在100kg以上的机组维修或生产加注

7、制冷行业:制冷剂加注或常压制冷剂的加压工作

8、制冷剂生产行业：制冷剂的灌装及大罐残液的回收

1. Suitable for conveying various refrigerants such as R22, R134a, R407C, R410A, etc

2. This device is used for the central conveying and boosting station of refrigerant that requires long-distance transportation in the refrigeration industry production

3. It can save the process of refrigerant handling and gas storage tank replacement on the production line, save manpower, and reduce refrigerant waste

4. Fully pneumatic operation, no power required

5. Fully automated operation, saving manpower

6. Refrigeration industry: Maintenance or production filling of units with refrigerant filling capacity of over 100kg

7. Refrigeration industry: refrigerant charging or pressurization of atmospheric pressure refrigerants

8. Refrigerant production industry: refrigerant filling and recovery of residual liquid from large tanks

三、进口氟利昂增压泵应用范围

1、用于甲烷气体增压，可以从大瓶灌装小瓶

2、用于甲烷气体高压反应实验，用于煤矿甲烷气体标准气体检测

3、灌装小气瓶

4、甲烷气体回收

1. Used for methane gas pressurization, can be filled from large bottles to small bottles

2. Used for high-pressure methane gas reaction experiments and for detecting methane gas standard gases in coal mines

3. Filling small gas cylinders

4. Methane gas recovery
