一、进口丁烷增压泵概述

威盾VTON丁烷增压泵，Butane booster pump，采用单气控非平衡气体分配阀来实现泵的自动往复运动，泵体气驱部分采用铝合金制造。接液部分根据介质不同选用碳钢或不锈钢，泵的全套密封件均为进口优质产品，从而保证了泵的性能。

本系列驱动活塞直径为160mm。最大驱动气压为10bar，为了保证泵的寿命，建议使用气压<8bar。

Weidun VTON Butane booster pump， The pump adopts a single gas controlled non-equilibrium gas distribution valve to achieve automatic reciprocating motion, and the gas driven part of the pump body is made of aluminum alloy. The liquid receiving part is made of carbon steel or stainless steel according to different media, and the complete set of seals for the pump are imported high-quality products, ensuring the performance of the pump.

The diameter of the drive piston in this series is 160mm. The maximum driving air pressure is 10 bar. To ensure the lifespan of the pump, it is recommended to use an air pressure of less than 8 bar.

二、进口丁烷增压泵系统原理

丁烷增压泵是利用活塞两端的面积差而获得高压气体（液体）输出，活塞的驱动气体端是低压，另一端活塞是高压小面积，增压泵活塞杆两端体积不同，将驱动气体通入与大活塞相连的腔，通过气控换向阀，大活塞可以往复运动，小活塞也往复运动。在活塞运动过程中，根据帕斯卡原理，在小活塞端产生高压气体(液体），泵往复工作，随着输出压力接近设定压力值时，泵往复工作减慢直至停止，此时气压力和液压力平衡，活塞基本保持静止，此时能量消耗最低，流体温度不再增加，反之当压力降低时泵开始工作。

The butane booster pump uses the area difference between the two ends of the piston to obtain high-pressure gas (liquid) output. The driving gas end of the piston is low-pressure, and the other end of the piston is high-pressure with a small area. The two ends of the booster pump piston rod have different volumes, and the driving gas is introduced into the chamber connected to the large piston. Through the pneumatic directional valve, the large piston can move back and forth, and the small piston can also move back and forth. During the movement of the piston, according to Pascal's principle, high-pressure gas (liquid) is generated at the small piston end, and the pump works back and forth. As the output pressure approaches the set pressure value, the reciprocating work of the pump slows down until it stops. At this time, the air pressure and hydraulic pressure are balanced, and the piston basically remains stationary. At this time, the energy consumption is the lowest, and the fluid temperature no longer increases. Conversely, when the pressure decreases, the pump starts to work.

三、进口丁烷增压泵产品特点

1、气体驱动：安全，无产生热.火星、火花的危险

2、密封性能好：无油润滑，三套动态密封装置用于将丁烷气体压缩缸与空气驱动缸分离，保证压缩丁烷气不被驱动气体污染及高压力的输出能力

3、出入口压力范围宽：对丁烷气进出口压力适应范围广范，没有限制，最大压力输出值为15Mpa

4、自冷却：驱动端排出的低温膨胀废气作冷却介质通入增压端自带的热交换器来冷却高压端的钢套及高压气体

5、易维护：体积小、重量轻、密封件寿命长，连续开机无限制

6、压力和流量调整范围宽：在泵的压力范围内，通过调节进气口压力及流量，输出的压力和流量相应得到的无级调整

7、易于控制：可在任何预定压力下自动停机，可远程控制，而且运行期间无能耗量

1. Gas driven: safe, no heat generation The danger of Mars and sparks

2. Good sealing performance: oil-free lubrication, three sets of dynamic sealing devices are used to separate the butane gas compression cylinder from the air driven cylinder, ensuring that the compressed butane gas is not contaminated by the driving gas and has high pressure output capacity

3. Wide range of inlet and outlet pressures: Suitable for a wide range of butane gas inlet and outlet pressures without restrictions, with a maximum pressure output value of 15Mpa

4. Self cooling: The low-temperature expansion exhaust gas discharged from the driving end is used as a cooling medium and passed into the heat exchanger provided by the boosting end to cool the steel sleeve and high-pressure gas at the high-pressure end

5. Easy to maintain: small size, light weight, long sealing life, unlimited continuous startup

6. Wide range of pressure and flow adjustment: Within the pressure range of the pump, by adjusting the inlet pressure and flow rate, the output pressure and flow rate can be continuously adjusted accordingly

7. Easy to control: can automatically shut down at any predetermined pressure, can be remotely controlled, and there is no energy consumption during operation
