一、VCC型系列手动超高真空插板阀概述

VCC型系列超高真空插板阀是通过手轮以螺杆传动，经传动杆推（拉）动连杆机构，驱动阀板沿轴向运动，实现阀门的开启或关闭，从而达到在超高真空系统中接通或切断气流的目的。在结构设计上合理，在外观上美观，并具有动作平稳，体积小，流道大，使用可靠。密封性能好和寿命长等优点，能广泛应用于超高真空设备中。
适用的工作介质为洁净的空气和非腐蚀性气体。

The VCC series ultra-high vacuum plug valve is driven by a screw through a handwheel, and the connecting rod mechanism is pushed (pulled) by the transmission rod to drive the valve plate to move in the axial direction, realizing the opening or closing of the valve, thereby achieving the purpose of connecting or cutting off the airflow in the ultra-high vacuum system. Reasonable in structural design, aesthetically pleasing in appearance, with smooth movement, small volume, large flow channel, and reliable use. The advantages of good sealing performance and long service life can be widely used in ultra-high vacuum equipment.

The applicable working medium is clean air and non corrosive gases.

二、进口手动超高真空插板阀主要技术性能
