一、进口高温磁力离心泵概述

高温磁力离心泵通常由电动机，磁力偶合器和耐腐蚀离心泵组成。其主要特点是利用磁力偶合器传递动力、完全无泄漏采用多重循环冷却结构，保证了原动力和磁传动的可靠性和稳定性，同时采用柱销联轴器减少了泵的噪音和震动，便拆式和柱销联轴器同时使用，使泵的结构增长，更有利于泵的散热。同时，也十分方便用户的维修或更换零件，在泵的外转子部分还设计了散热风叶，确保磁钢的稳定性。V-CQB系列磁力泵是磁力泵开发的新型完全无泄漏耐腐泵。

High temperature magnetic centrifugal pumps are usually composed of electric motors, magnetic couplings, and corrosion-resistant centrifugal pumps. Its main feature is the use of magnetic couplings to transmit power, completely leak free use of multiple circulation cooling structure, ensuring the reliability and stability of the original power and magnetic transmission. At the same time, the use of column pin couplings reduces the noise and vibration of the pump, allowing for both detachable and column pin couplings to be used simultaneously, increasing the structure of the pump and facilitating heat dissipation. At the same time, it is also very convenient for users to repair or replace parts. A cooling fan blade is also designed on the outer rotor of the pump to ensure the stability of the magnetic steel. The V-CQB series magnetic pump is a new type of completely leak free and corrosion-resistant pump developed by magnetic pumps.

二、高温磁力离心泵产品特点
泵的过流部件根据需要可分别采用304、304L、321、316、316L、CD4MCu、等耐腐材料。流量 3.2～100m3/h扬程8～80m，转速2900r/min

The overcurrent components of the pump can be made of 304, 304L, 321, 316, 316L according to the needs CD4MCu、 Waiting for corrosion-resistant materials. Flow rate of 3.2-100m3/h, head of 8-80m, speed of 2900r/min

三、高温磁力离心泵产品用途
不含固体颗粒腐蚀液体、强酸、强碱、乙醇、漂白剂、照相液、硝酸、盐酸、氢氟酸、醋酸、氢氧化纳、丙酮、四氧乙烷、海水、盐水等等。

Does not contain corrosive liquids such as solid particles, strong acids, strong bases, ethanol, bleaching agents, photographic fluids, nitric acid, hydrochloric acid, hydrofluoric acid, acetic acid, sodium hydroxide, acetone, ethylene oxide, seawater, saltwater, etc.
