一、进口卡箍卫生级科里奥利流量计概述

卡箍卫生级科里奥利流量计采用卡箍快装的连接方式，科里奥利原理的测量方法，是一种先进的高精度质量流量测量仪表，由于其优异的性能，使其测量准确度高、对流体状态要求低、压力损失小、多种规格的科里奥利力(简称科氏力)仪表都可以直接获得被测量液体或浆液的质量流量、体积流量密度、温度、无需人工计算或估算，即使在恶劣的工作环境下也能表现出优异的性能，其内部没有活动部件，不需复杂的安装，对工况条件也没有苛刻的要求，每台传感器都由不锈钢材料制造，变送器的多种输出能满足您的各种需要。

产品适合测量几乎所有的无固态颗粒物的流体 ， 主要用于石油、化工、食品、环保等行业。

The clamp hygiene grade Coriolis flowmeter adopts a clamp quick installation connection method and the measurement method of Coriolis principle. It is an advanced high-precision mass flow measurement instrument. Due to its excellent performance, it has high measurement accuracy, low requirements for fluid state, small pressure loss, and can directly obtain the mass flow rate, volume flow density, temperature of the measured liquid or slurry with various specifications of Coriolis force (referred to as Coriolis force) instruments without manual calculation or estimation. Even in harsh working environments, it can show excellent performance. There are no moving parts inside, no need for complex installation, and no strict requirements for working conditions. Each sensor is made of stainless steel material, and the multiple outputs of the transmitter can meet your various needs.

The product is suitable for measuring almost all fluids without solid particles, mainly used in industries such as petroleum, chemical, food, and environmental protection.

二、进口卡箍卫生级科里奥利流量计特点

1、采用先进的卫生型设计， 适用于要求最佳清洁能力的食品和饮料行业中的应用场合。

2、自排空的单测量管系统能够进行敏感流体测量。

3、与一体式变送器配套使用操作灵活，系统集成便捷。

4、在仪表的同一侧接线、远程显示、改进的连接方式。

5、测量原理不受流体物理特性的影响(例如：粘度和密度)。

6、卫生型应用条件下要求最佳清洁能力的专用流量计。

7、多种卫生型过程连接。

8、CIP/SIP清洗后能够快速恢复。

9、一体式卫生型双腔室外壳，IP69，最多带 3 路输入/输出。

10、背光显示、触摸键控制和WLAN访问。

11、提供分离型显示单元。

1. Adopting advanced hygienic design, suitable for applications in the food and beverage industry that require optimal cleaning capabilities.

2. The self emptying single measuring tube system is capable of measuring sensitive fluids.

3. Flexible operation and convenient system integration when used in conjunction with integrated transmitters.

4. Wiring on the same side of the instrument, remote display, and improved connection methods.

5. The measurement principle is not affected by the physical properties of the fluid, such as viscosity and density.

6. A specialized flow meter that requires optimal cleaning capability under hygienic application conditions.

7. Multiple sanitary process connections.

8. CIP/SIP cleaning can quickly restore.

9. Integrated sanitary dual chamber housing, IP69, with up to 3 inputs/outputs.

10. Backlight display, touch key control, and WLAN access.

11. Provide separate display units.
