一、进口高精度电磁流量计概述

进口高精度电磁流量计是一种高智能、高可靠性的流量计,不仅可用于一般的过程检测,还适用于矿浆、纸浆及糊状液体的测量，广泛应用于石油、化工、钢铁、食品、电力、造纸、水利给排水、水政水资源等行业。

High precision electromagnetic flowmeter is a highly intelligent and reliable flowmeter, which can be used not only for general process detection, but also for the measurement of pulp, pulp, and paste liquids. It is widely used in industries such as petroleum, chemical, steel, food, electricity, papermaking, water supply and drainage, and water resources.

二、进口高精度电磁流量计特点

1、测量精度不受流体密度、粘度、温度、压力和电导率变化的影响。

2、测量管无阻碍、无活动部件、无压损，直管段要求较低。

3、电磁流量传感器可带接地电极，实现仪表良好接地。

4、电磁流量传感器采用先进加工工艺，使仪表具有良好的抗负压能力。

5、全数字量处理，抗干扰能力强，测量可靠，***度高。

6、高清晰度背光LCD显示，全汉字菜单操作，使用方便，操作简单，在强光下货夜晚都能清晰读书。

7、具有双向流量、双向总量累计功能，电流、频率具备双向输出功能。

8、仪表系统测量精度高，使用范围宽，不是可用于污水、水泥浆液矿浆液等的测量，还可用于强酸、强碱液体流量的测量。

9、转换器输出功能强大：不但具有4-20mA、脉冲输出，还具有RS485或RS232、HART 等数字通讯以及GPRS无线数据远传。

1. The measurement accuracy is not affected by changes in fluid density, viscosity, temperature, pressure, and conductivity.

2. The measuring tube has no obstruction, no moving parts, and no pressure loss, and the requirements for straight pipe sections are relatively low.

3. Electromagnetic flow sensors can be equipped with grounding electrodes to achieve good instrument grounding.

4. The electromagnetic flow sensor adopts advanced processing technology, which makes the instrument have good anti negative pressure ability.

5. Fully digital processing, strong anti-interference ability, reliable measurement, and high * * * degree.

6. High definition backlight LCD display, full Chinese character menu operation, convenient to use, simple to operate, can read clearly even under strong light and at night.

7. It has bidirectional flow and bidirectional total accumulation functions, and bidirectional output functions for current and frequency.

8. The instrument system has high measurement accuracy and a wide range of applications. It is not suitable for measuring sewage, cement slurry, mineral slurry, etc., but can also be used for measuring the flow rate of strong acid and strong alkali liquids.

9. The converter has powerful output function: it not only has 4-20mA and pulse output, but also has digital communication such as RS485 or RS232, Hart, and GPRS wireless data transmission.
