一、进口双金属片式疏水阀产品概述

进口双金属片式疏水阀，Bimetallic steam trap，也叫双金属片式疏水器，双金属片式蒸汽疏水阀，双金属片式蒸汽疏水器，主要部件是双金属片感温元件，随蒸汽温度升降受热变形，推动阀心开关阀门。双金属片式疏水阀设有调整螺栓，可根据需要调节使用温度，一般过冷度调整范围低于饱和温度15℃-30℃，背压率大于70%，能排不凝结气体，不怕冻，体积小，能抗水锤，耐高压，任意位置都可安装。双金属片有疲劳性，须要经常调整。

双金属片式疏水阀适用于散热器、换热器、夹套锅、加热盘管、烘干机、消毒器、层压机等。

Double metal plate drain valve, Bimetallic steam trap， Also known as bimetallic plate type steam trap, bimetallic plate type steam trap, bimetallic plate type steam trap, the main component is a bimetallic plate temperature sensing element, which is heated and deformed with the rise and fall of steam temperature, pushing the valve core to open and close the valve. The bimetallic plate drain valve is equipped with adjustment bolts, which can adjust the operating temperature according to needs. Generally, the adjustment range of undercooling is below the saturation temperature of 15 ℃ -30 ℃, with a back pressure rate greater than 70%. It can discharge non condensable gases, is not afraid of freezing, has a small volume, can withstand water hammer, high pressure, and can be installed in any position. The bimetallic sheet has fatigue and needs to be adjusted regularly.

The bimetallic plate type drain valve is suitable for radiators, heat exchangers, jacketed pots, heating coils, dryers, disinfectors, laminators, etc.

二、进口双金属片式疏水阀原理

当装置刚起动时，管道出现低温冷凝水，双金属片是平展的，阀心在弹簧的弹力下，阀门处于开启位置。当冷凝水温度渐渐升高，双金属片感温起元件开始弯曲变形，并把阀心推向关闭位置。在冷凝水达到饱和温度之前，疏水阀开始关闭。双金属片随蒸汽温度变化控制阀门开关，阻汽排水。

When the device is just started, low-temperature condensation water appears in the pipeline, the bimetallic plate is flat, and the valve core is in the open position under the spring force. As the temperature of the condensate gradually increases, the bimetallic temperature sensing element begins to bend and deform, pushing the valve core towards the closed position. Before the condensate reaches saturation temperature, the drain valve begins to close. The bimetallic sheet controls the valve opening and closing with changes in steam temperature, preventing steam and draining water.

三、进口双金属片式疏水阀产品特点

1、双金属片式疏水阀排放温度可在闲调解，安装姿势自由，内件全不锈钢。

2、双金属片式疏水阀利用高温凝结水行程水封式，有效减少蒸汽泄漏。

3、双金属片式疏水阀动作灵敏，抗水击，无噪音，排空性能优良。

4、双金属片式疏水阀结构简单，容易维修保养，适用高温蒸汽管线。

1. The discharge temperature of the bimetallic plate drain valve can be adjusted freely, and the installation posture is free. The internal components are all made of stainless steel.

2. The bimetallic plate type drain valve utilizes a water sealed high-temperature condensate stroke to effectively reduce steam leakage.

3. The bimetallic plate type drain valve has sensitive operation, water hammer resistance, no noise, and excellent emptying performance.

4. The bimetallic plate type drain valve has a simple structure, is easy to maintain, and is suitable for high-temperature steam pipelines.
