一、进口热静力波纹管式疏水阀产品概述

进口热静力波纹管式疏水阀，Thermostatic bellows steam trap，也叫热静力波纹管式疏水器，热静力波纹管式蒸汽疏水阀，热静力波纹管式蒸汽疏水器，根据阀腔内温度的变化是成波纹管内感温液体的汽化或冷凝，波纹管的内压产生变化而驱使波纹管带动阀芯作移位启闭阀座孔，达到阻汽排水。该阀能充分利用热能．特别适用于蒸汽伴热管线，是低温排水的环保型现热疏水阀。

Thermostatic bellows type drain valve, Thermostatic bellows steam trap， Also known as thermal static corrugated pipe type steam trap, thermal static corrugated pipe type steam trap, thermal static corrugated pipe type steam trap, according to the temperature change in the valve chamber, it vaporizes or condenses the temperature sensitive liquid inside the corrugated pipe. The change in internal pressure of the corrugated pipe drives the corrugated pipe to move the valve core to open and close the valve seat hole, achieving steam blocking and drainage. This valve can fully utilize thermal energy and is particularly suitable for steam tracing pipelines. It is an environmentally friendly on-site drain valve for low-temperature drainage.

二、进口热静力波纹管式疏水阀产品特征

1、排水温度可以调节在70~100之间，使用方便。

2、能够阻止高温凝结水的排放，保持蒸汽管线的热能。

3、连续排放，没有噪音。蒸汽压力的小波动没有影响使用。

4、构简单，安装方便，随意。

5、具有良好的排空性能，不怕冻。零泄漏，背压率达到75%以上。

1. The drainage temperature can be adjusted between 70-100, making it convenient to use.

2. It can prevent the discharge of high-temperature condensate and maintain the thermal energy of the steam pipeline.

3. Continuous emission without noise. Small fluctuations in steam pressure do not affect usage.

4. Easy to construct, easy to install, and casual.

5. Has good emptying performance and is not afraid of freezing. Zero leakage, with a back pressure rate of over 75%.

三、进口热静力波纹管式疏水阀性能与材料
