一、进口热动力圆盘式疏水阀产品概述

进口热动力圆盘式疏水阀，Thermal power disc type drain valve，也叫热动力圆盘式疏水器，热动力圆盘式蒸汽疏水阀，热动力圆盘式蒸汽疏水器，是根据热动力学原理，利用蒸汽和凝结水的热动力学不同热性，引起动能和势能动静压变化，使动作件阀片上下压差变化，启动阀片开启和关闭，从而达到阻气排水目的。广泛用于蒸汽主管道，伴热管线、夹套锅及各种小型蒸汽设备。

Thermodynamic disc drain valve, Thermal power disc type drain valve， Also known as a thermal power disc steam trap, a thermal power disc steam trap, or a thermal power disc steam trap, it is based on the principles of thermodynamics and utilizes the different thermal properties of steam and condensate to cause dynamic and static pressure changes in kinetic energy and potential energy, resulting in a change in the pressure difference between the upper and lower parts of the valve plate. The starting valve plate opens and closes, thereby achieving the purpose of blocking gas and draining water. Widely used in steam main pipelines, heat tracing pipelines, jacketed boilers, and various small steam equipment.

二、进口热动力圆盘式疏水阀原理

热动力圆盘式疏水阀内有一个阀片，既是敏感件又是动作执行件。当装置启动时，管道出现冷却凝结水，凝结水靠工作压力推开阀片，迅速排放。当凝结水排放完毕，蒸汽进入疏水阀内，蒸汽的体积迅速扩大，蒸汽比凝结水的流速大，使阀片上下产生压差，阀片在蒸汽流速的吸力下迅速关闭。当阀片关闭时，阀片受到两面压力，阀片下面的受力面积小于上面的受力面积，因疏水阀汽室里面的压力来源于蒸汽压力，所以阀片上面受力大于下面，阀片紧紧关闭。当疏水阀汽室里面的蒸汽降温成凝结水，汽室里面的压力消失。凝结水靠工作压力推开阀片，凝结水又继续排放，循环工作，间断排水。

There is a valve plate inside the thermal power disc drain valve, which is both a sensitive component and an action actuator. When the device is started, cooling condensate appears in the pipeline, and the condensate is quickly discharged by pushing open the valve plate under working pressure. When the condensate is discharged, steam enters the drain valve, and the volume of steam rapidly expands. The flow rate of steam is higher than that of condensate, causing a pressure difference between the upper and lower parts of the valve plate. The valve plate quickly closes under the suction of steam flow rate. When the valve disc is closed, it is subjected to pressure on both sides, and the force area under the valve disc is smaller than the force area above. Because the pressure inside the steam chamber of the drain valve comes from steam pressure, the force on the valve disc is greater than that on the bottom, and the valve disc is tightly closed. When the steam in the steam trap chamber cools down to condensate, the pressure inside the chamber disappears. The condensate relies on the working pressure to push open the valve plate, and the condensate continues to discharge, circulating and intermittently draining.

三、进口热动力圆盘式疏水阀产品特点

1、热动力圆盘式疏水阀结构结实、重量轻、体积小使用压力范围大，不需任何调节。

2、热动力圆盘式疏水阀具有空气排放装置，迅速排除初时空气、保证快速启动。

3、热动力圆盘式疏水阀可承受过热蒸汽、抗冰冻能力强，安装位置不受限制，均能正常工作。

1. The thermal power disc type drain valve has a sturdy structure, light weight, small volume, and a large pressure range, without any adjustment.

2. The thermal power disc drain valve has an air discharge device, which quickly removes the initial air and ensures quick start-up.

3. The thermal power disc drain valve can withstand superheated steam and has strong anti freezing ability. The installation position is not limited and can work normally.

四、进口热动力圆盘式疏水阀零件材料
