一、进口倒吊桶式疏水阀产品概述

进口倒吊桶式疏水阀，Inverted bucket type steam trap，也叫倒吊桶疏水器，倒吊桶蒸汽疏水阀，吊桶蒸汽疏水器，倒置桶疏水阀，内部结构是杠杆系统连接倒置桶，开启与关闭是根据凝结水和蒸汽的密度差来工作的；管路启动时，疏水阀阀座处于开启状态，迅速将滞留管道的空气和低温冷凝水排出，当蒸汽进入倒置桶内，倒置桶产生向上浮力，桶上的链接杠杆带动阀瓣关闭阀门。当一部分蒸汽产生凝结水，桶内失去浮力下沉，倒吊桶连接杠杆带动阀瓣开启阀门。

Inverted bucket type drain valve, Inverted bucket type steam trap， Also known as inverted bucket steam trap, inverted bucket steam trap, inverted bucket steam trap, inverted bucket steam trap, the internal structure is a lever system connected to the inverted bucket, and opening and closing work based on the density difference between condensate and steam; When the pipeline is started, the valve seat of the drain valve is in an open state, quickly discharging the air and low-temperature condensate trapped in the pipeline. When steam enters the inverted bucket, the inverted bucket generates upward buoyancy, and the connecting lever on the bucket drives the valve disc to close the valve. When a portion of the steam produces condensate, the bucket loses buoyancy and sinks. The inverted bucket is connected to a lever to drive the valve disc to open the valve.

二、进口倒吊桶式疏水阀特点

1、即能连续又能间歇排放饱和凝结水加热设备不会有水积聚，从而获得最离的热效率。

2、耐水击侧吊桶结构不会因水击而遭到损坏，使用寿命长。

3、排空气性能好倒吊桶上设有溢出排气孔．可有效地预防蒸汽气锁和空气气堵。

4、允许背压高背压率达85 ％。

5、维修方便内部零件采用不锈钢制造，均安装在阀盖上，并设有过滤网装置，日常维护方便。

1. The heating equipment can continuously and intermittently discharge saturated condensate without water accumulation, thus achieving the most efficient thermal efficiency.

2. The water-resistant side bucket structure will not be damaged by water hammer and has a long service life.

3. The inverted bucket has good air exhaust performance and is equipped with overflow exhaust holes, which can effectively prevent steam lock and air blockage.

4. Allow a high back pressure rate of 85%.

5. The internal parts are made of stainless steel and installed on the valve cover, with a filter screen device for easy maintenance.
