一、进口不锈钢刀闸阀概述

进口不锈钢刀闸阀（闸阀），Stainless steel knife gate valve，又名不锈钢刀型闸阀，不锈钢刀阀，阀体和阀板均采用不锈钢材质，启闭件为刀型的阀板，其闸板具有剪切功能，可刮除密封面上的粘着物，自动清除杂物，不锈钢闸板可防止腐蚀引起的密封泄漏的闸阀。

美国威盾VTON具不锈钢刀闸阀有结构紧凑、设计合理、轻型节材,密封可靠、操作轻便灵活、体积小、通道流畅、流阻小、重量轻、易安装、易拆卸等优点，可在工作压力0.6MPa-1.6MPa，使用温度-29-550℃情况下正常工作。主要产品有：对夹刀闸阀，法兰刀闸阀，气动刀闸阀，电动刀闸阀，不锈钢刀闸阀，不锈钢板刀闸阀，不锈钢硬密封刀闸阀，广泛满足造纸、纸浆工业、工业污水和城市污水处理、化工厂、飞灰处理、散状物料输送、食品饮料工业的使用要求及工作条件苛放慢的环境条件下。

Stainless steel knife gate valve (gate valve), Stainless steel knife gate valve， Also known as stainless steel knife type gate valve, stainless steel knife type gate valve. The valve body and valve plate are made of stainless steel material, and the opening and closing parts are knife type valve plates. The gate plate has a shearing function, which can scrape off the adhesive on the sealing surface and automatically remove debris. The stainless steel gate plate can prevent sealing leakage caused by corrosion in the gate valve.

The American Weidun VTON stainless steel knife gate valve has the advantages of compact structure, reasonable design, lightweight material saving, reliable sealing, light and flexible operation, small volume, smooth channel, small flow resistance, light weight, easy installation, and easy disassembly. It can work normally under working pressure of 0.6MPa-1.6MPa and operating temperature of -29-550 ℃. The main products include: clamp knife gate valve, flange knife gate valve, pneumatic knife gate valve, electric knife gate valve, stainless steel knife gate valve, stainless steel plate knife gate valve, stainless steel hard sealed knife gate valve, which are widely used in the papermaking, pulp industry, industrial sewage and urban sewage treatment, chemical plants, fly ash treatment, bulk material transportation, food and beverage industry under harsh and slow working conditions.

二、进口铸钢刀闸阀产品特点

1、设计紧凑、占据空间小、重量轻、易于安装、耐磨防堵措施完善，便于维修，使用寿命长。

2、根据需要，可在阀体四周设置多个冲洗口，直接用空气、蒸汽或水进行冲洗，防止沉淀物逐渐堆积，对于输入困难的流体特别适用。

3、聚胶脂或含Ni耐磨铸铁制成的耐磨折边锥体安装在刀闸阀的进口端，可防止颗粒物料直接冲刷在密封上，从而可改善的工作条件，延长寿命。

4、在刀板上端安装有聚四氟乙烯、刮泥器，可防止粉尘砂砾等擦伤性物质进入填料盒。

5、采用全圆形的通道设计，刀板底端加工成刀刃，光洁度高，保证了良好的密封性。

1. Compact design, small space occupation, light weight, easy installation, complete wear-resistant and anti blocking measures, easy maintenance, and long service life.

2. As needed, multiple flushing ports can be installed around the valve body, which can be directly flushed with air, steam, or water to prevent the gradual accumulation of sediment. It is particularly suitable for fluids that are difficult to input.

3. The wear-resistant folding cone made of polyester or Ni containing wear-resistant cast iron is installed at the inlet end of the knife gate valve, which can prevent particle materials from directly flushing onto the seal, thereby improving working conditions and extending service life.

4. A polytetrafluoroethylene and a scraper are installed on the upper end of the blade to prevent abrasive substances such as dust and gravel from entering the packing box.

5. Adopting a fully circular channel design, the bottom of the blade is processed into a blade, with high smoothness, ensuring good sealing performance.

三、进口不锈钢刀闸阀主要零部件材质

四、进口不锈钢刀闸阀主要性能参数

五、进口不锈钢刀闸阀主要外形图
