一、进口电动调节型硬密封对夹蝶阀概述

进口电动调节型硬密封对夹蝶阀采用精密的J形弹性密封圈和三偏心多层次金属硬密封结构，被广泛用于介质温度≤425℃的治金 、电力、石油化工、以及给排水和市政建设等工业管道上，作调节流量和载断流体使用。该阀采用三偏心结构，阀座与碟板密封面均采用不同硬度和不锈钢制作，具有良好的耐腐蚀性，使用寿命长，本阀均有双向密封功能。

The electrically adjustable hard sealed clamp butterfly valve adopts a precise J-shaped elastic sealing ring and a three eccentric multi-level metal hard sealing structure. It is widely used in industrial pipelines such as metallurgy, power, petrochemicals, water supply and drainage, and municipal construction where the medium temperature is ≤ 425 ℃, for regulating flow rate and breaking fluid. The valve adopts a three eccentric structure, and the sealing surfaces of the valve seat and disc plate are made of different hardness and stainless steel, which has good corrosion resistance and long service life. This valve has a bidirectional sealing function.

美国威盾VTON电动硬密封蝶阀耐磨，耐温，耐压，主要产品有电动双偏心硬密封蝶阀，电动碳钢硬密封蝶阀，电动不锈钢硬密封蝶阀，电动硬密封对夹蝶阀，电动硬密封法兰蝶阀，电动硬密封调节蝶阀，进口电动双偏心硬密封蝶阀。

VTON electric hard sealed butterfly valves are wear-resistant, temperature resistant, and pressure resistant. Our main products include electric double eccentric hard sealed butterfly valves, electric carbon steel hard sealed butterfly valves, electric stainless steel hard sealed butterfly valves, electric hard sealed clamp butterfly valves, electric hard sealed flange butterfly valves, electric hard sealed regulating butterfly valves, and imported electric double eccentric hard sealed butterfly valves.

二、进口电动调节型硬密封对夹蝶阀产品特点

1、采用三偏心密封结构，阀座与蝶板几乎无磨损，具有越观越紧的密封功能。

2、密封圈选用不锈钢制作，具有金属硬密封和弹性密封的双重优点，无论在低温和高温的情况下，均具有优良的密封性能，具有耐腐蚀,使用寿命长等特点。

3、碟板密封面采用堆焊钴基硬质合金，密封面耐磨损，使用寿命长．

4、大规格蝶板采用绗架结构，强度高，过流面积大，流阻小。

5、本阀具有双向密封功能，安装时不受介质流向的限制，也不受空间位置的影响，可在任何方向安装。

6、驱动装置可以多工位（旋转90°或180°）安装，便于用户使用。

1. Adopting a three eccentric sealing structure, the valve seat and butterfly plate have almost no wear, and have a sealing function that becomes tighter and tighter.

2. The sealing ring is made of stainless steel, which has the dual advantages of metal hard sealing and elastic sealing. It has excellent sealing performance in both low and high temperature conditions, corrosion resistance, and long service life.

3. The sealing surface of the disc plate is made of cobalt based hard alloy, which is wear-resistant and has a long service life

4. The large-sized butterfly plate adopts a quilted frame structure, which has high strength, large overcurrent area, and low flow resistance.

5. This valve has a bi-directional sealing function, and is not limited by the flow direction of the medium or affected by spatial position during installation. It can be installed in any direction.

6. The drive device can be installed at multiple workstations (rotating 90 ° or 180 °) for user convenience.

进口电动调节型硬密封对夹蝶阀主要参数

公称通经DN（mm) 50～2000

公称药理PN（MPa) 0.6 1.0 1.6 2.5

密封试验(MPa) 0.66 1.1 1.76 2.75

强度试验(MPa) 0.9 1.5 2.4 3.75

适用温度 碳钢：-29℃～425℃ 不锈钢：-40℃～650℃

适用介质 水、空气、天然气、油品及弱腐蚀性流体

泄漏率 符合GB/T13927-92标准

驱动方式 蜗轮传动、电动、气动、液动
