一、进口气动调节型球阀概述

美国威盾进口气动调节型球阀由带定位器的角行程执行器和球阀组成。接受4-20Ma的信号，开度调节，适用于调节流量的场合。球阀与执行机构的连接采用直连方式。具有连线简单，结构紧凑、尺寸小、重量轻、阻力小、动作稳定可靠等优点。

The VTON pneumatic regulating ball valve consists of an angle stroke actuator with a locator and a ball valve. Accepting 4-20Ma signal, adjusting the opening, suitable for adjusting flow rate. The connection between the ball valve and the actuator adopts a direct connection method. It has the advantages of simple connection, compact structure, small size, light weight, low resistance, and stable and reliable operation.

二、进口气动调节型球阀结构特征

①调节精度高，误差不大于2%；

②密封性可靠，流通性能好，流阻小，装卸方便；

③采用直连方式，具有连线简单，结构紧凑，动作稳定；

④适用于粘稠、含颗粒、纤维场合，广泛用于石油、化工、冶金、轻工、造纸、电站、制冷等工作领域。

⑤还有特殊功能的气动球阀，比如气动高压球阀，气动保温球阀，气动三通球阀等

① High adjustment accuracy, with an error not exceeding 2%;

② Reliable sealing, good circulation performance, low flow resistance, and convenient loading and unloading;

③ Adopting direct connection method, it has simple connection, compact structure, and stable action;

④ Suitable for viscous, particle containing, and fiber containing situations, widely used in fields such as petroleum, chemical, metallurgical, light industry, papermaking, power plants, refrigeration, etc.

⑤ There are also pneumatic ball valves with special functions, such as pneumatic high-pressure ball valves, pneumatic insulated ball valves, pneumatic three-way ball valves, etc.

三、进口气动调节型球阀性能参数
