一、进口防爆电动开关球阀产品概述

美国威盾VTON进口防爆电动开关球阀由角行程防爆电动执行器及球阀球体组成，是由电子式角行程电动执行机构3610R或HQ系列与球阀调节机构组成，电动执行器的电气防爆的等级一般为防爆等级为ExdⅡBT4-BT6。用于易燃易爆的场合，需要对电气进行防爆的场所。

电动防爆球阀具有结构简，切换迅速、流通能力大，零泄漏等特点，适用于高粘度、含纤维、固体颗粒流体的场合，电动防爆球阀广泛应用于石油化工，冶金、轻工等工业自控领域对气体、液体输送管道中介质的切断或流通。执行器采用一体化设计，输入220V电源即可直接进行开关量调节，亦可内置伺服模块，输入控制信号(4～20mADC或1～5VDC)及单相电源即可控制运转。

电动防爆球阀防爆等级为ExdⅡBT4、防护等级为IP67、可带现场控制装置。电动防爆球阀主要特点为：不通电时，扳动离合器手柄可进行手动操作。通电时，离合器自动复位。流向可任意，可调范围广，能用于高压和大口径场合，控制高粘度，带有纤维和细颗粒的介质。

The VTON explosion-proof electric switch ball valve is composed of an angle travel explosion-proof electric actuator and a ball valve ball. It is composed of an electronic angle travel electric actuator 3610R or HQ series and a ball valve regulating mechanism. The electrical explosion-proof level of the electric actuator is generally Exd Ⅱ BT4-BT6. Used in flammable and explosive environments where electrical explosion-proof measures are required.

Electric explosion-proof ball valves have the characteristics of simple structure, fast switching, large flow capacity, and zero leakage. They are suitable for high viscosity, fiber containing, and solid particle fluids. Electric explosion-proof ball valves are widely used in industrial self-control fields such as petrochemicals, metallurgy, and light industry to cut off or flow media in gas and liquid transportation pipelines. The actuator adopts an integrated design, and can directly adjust the switch value by inputting a 220V power supply. It can also be equipped with a servo module. The operation can be controlled by inputting control signals (4-20mADC or 1-5VDC) and a single-phase power supply.

The electric explosion-proof ball valve has an explosion-proof rating of Exd Ⅱ BT4, a protection rating of IP67, and can be equipped with on-site control devices. The main feature of electric explosion-proof ball valves is that when not powered on, manual operation can be performed by pulling the clutch handle. When powered on, the clutch automatically resets. The flow direction can be arbitrary, with a wide adjustable range, and can be used in high-pressure and large-diameter situations, controlling high viscosity media with fibers and fine particles.

二、进口防爆电动开关球阀主要技术参数及性能
