一、进口承插焊球阀概述

进口承插焊球阀（美国威盾VTON），Socket weld ball valve，也叫三片式承插焊球阀，承插焊不锈钢球阀，承插焊三片式球阀，是指采用承插焊的连接方式，用带有圆形通道的球体作启闭件，球体随阀杆转动实现启闭动作的阀门，其启闭件是一个有孔的球体，绕垂直于通道的轴线旋转，从而达到启闭通道的目的。

Socket weld ball valve (VTON), also known as three piece socket weld ball valve, socket weld stainless steel ball valve, socket weld three piece ball valve, refers to a valve that uses a socket weld connection method, uses a ball with a circular channel as the opening and closing part, and the ball rotates with the valve stem to achieve the opening and closing action. The opening and closing part is a perforated ball that rotates around the axis perpendicular to the channel, thereby achieving the purpose of opening and closing the channel.

二、进口承插焊球阀应用范围
适用介质:水、油、气及某些腐蚀液体
三片式承插焊球阀适用介质：水、油、气及某些腐蚀性液体（W.O.G）
三片式承插焊球阀适用稳定范围：-20～232℃～350℃
三片式承插焊球阀公称压力：1.6-6.4MPa

三、进口承插焊球阀结构特点

1. 进口承插焊球阀流体阻力小。
2. 进口承插焊球阀结构简单,相对体积小,重量轻,便于维修。
3. 进口承插焊球阀 密封性能好。
4. 进口承插焊球阀不受安装方向的限制,介质的流向可任意。
5. 进口承插焊球阀无振动,噪声小。

1. Socket welded ball valves have low fluid resistance.

2. Socket welded ball valves have a simple structure, relatively small volume, light weight, and are easy to maintain.

3. The socket welded ball valve has good sealing performance.

4. The socket welding ball valve is not limited by the installation direction, and the flow direction of the medium can be arbitrary.

5. The socket welded ball valve has no vibration and low noise.

四、进口承插焊球阀零件材料与工况
