一、进口热水焊接球阀概述

进口热水焊接球阀（美国威盾VTON），Hot water welded ball valve，也叫热水管网球阀，热水供水焊接球阀，热水回水焊接球阀，小区热水管网球阀，是指采用20号钢为阀体，以不锈钢为球体，采用全焊接的连接方式，采用碳强化PTFE斜面弹性密封圈负压在球面上，用于各种工厂的供暖供热的管网的热水管道介质，使密封达到零泄漏，使用寿命长。应用于小区的供暖供热管网。

Hot water welded ball valve (VTON, USA), also known as hot water pipeline ball valve, hot water supply welding ball valve, hot water return welding ball valve, residential hot water pipeline ball valve, refers to the use of 20 # steel as the valve body, stainless steel as the ball, using a fully welded connection method, carbon reinforced PTFE inclined elastic sealing ring negative pressure on the spherical surface, used for the hot water pipeline medium of heating and heating pipelines in various factories, to achieve zero leakage and long service life. Applied to the heating and supply network of residential areas.

二、进口热水焊接球阀应用领域

1）：城市燃气：燃气输出管道、主干线及各支线供应管道等。
2）：集中供热：大型供热设备输出管线、主干线、支线。
3）：热交换机：管道及各回路启闭。
4）：钢铁厂：各种流体管道、废气择放管道、煤气和热力供应管道、燃料供应管道。
5）：各种工业设备、各种热处理管道、各种工业煤气和热力管道。

三、进口热水焊接球阀产品特点

1）：不需要维护，调整及润滑，易于安装，在低运行费用下长期可靠运行。表面采用喷塑处理技术，光泽美观，在国内已处于领先水平。不会有外部泄漏等现象。阀体是焊接结构，所以阀门重量轻且易于进行绝缘。安装调节机构，非常简便，操作手柄可以拆下，换向安装。
2）：由于阀座是由碳纤维增强特氟隆密封环及碟形簧构成的，所以对压力和温度的变化适应能力强，在标注压力和温度范围内不会产生任何泄滑。
3）：球体的加工过程有先进的计算机检测仪跟踪检测，所以球体的加工精度高。
4）：由于阀体材料跟管道材质一样，不会出现应力不均，也不会由于地震及车辆经过地面时而产生变形，管道耐老化。
5）：整体式全焊接，等径及变径通道，采用固定球及浮动球，双活塞效应密封系统，自动
注入密封剂式轴承。
6）：为了防止静电，阀杆与球体以及阀杆与填料箱之间分别装有钢球和弹簧，可以保持阀门所有零件与阀体的导电，让电流通过区，释放静电。不仅防止火灾，而且防止腐蚀，实现临时性切断，以便及时检修。
7）：阀杆防脱功能是因为阀杆受阀内压力影响，总产生脱离的力所以阀杆设计成防脱结构。
8）：用低摩擦材料的止推垫圈支撑将压力推向阀杆，使阀杆仅仅起到传递扭矩的作用。

1) No maintenance, adjustment, or lubrication required, easy to install, and reliable long-term operation at low operating costs. The surface is treated with spray coating technology, which has a beautiful luster and is at the leading level in China. There will be no external leakage or other phenomena. The valve body is a welded structure, so the valve is lightweight and easy to insulate. Installing the adjustment mechanism is very simple, and the operating handle can be removed for reverse installation.

2) Due to the fact that the valve seat is composed of carbon fiber reinforced Teflon sealing rings and disc springs, it has strong adaptability to pressure and temperature changes, and will not produce any leakage within the marked pressure and temperature range.

3) The machining process of the sphere is tracked and detected by advanced computer detectors, so the machining accuracy of the sphere is high.

4) Due to the fact that the material of the valve body is the same as that of the pipeline, there will be no uneven stress, and there will be no deformation due to earthquakes or vehicles passing through the ground. The pipeline is resistant to aging.

5) : Integrated full welding, equal and variable diameter channels, using fixed and floating balls, dual piston effect sealing system, automatic

Inject sealing agent into the bearing.

6) To prevent static electricity, steel balls and springs are installed between the valve stem and the ball, as well as between the valve stem and the packing box, respectively, to maintain conductivity between all parts of the valve and the valve body, allowing current to pass through the area and release static electricity. Not only does it prevent fire, but it also prevents corrosion and achieves temporary cutting for timely maintenance.

7) The anti detachment function of the valve stem is designed as an anti detachment structure because the valve stem is affected by the pressure inside the valve, resulting in a total force of detachment.

8) Use a low friction material thrust washer to support and push pressure towards the valve stem, so that the valve stem only serves to transmit torque.

三、进口热水焊接球阀产品参数：

压力等级：1.6MPa~ 4.0MPa
产品规格：DN15 ~ 1000mm
产品材质：ST37.8，锻钢A105
适用温度：-29℃≤t≤150 ℃（跟阀体材质及密封面材质不同所承温有差异）
驱动方式：气动、电动、手动、蜗轮驱动等
阀体材质：铸钢、不锈钢、锻钢
阀 体：钢制Q235A
球 体：不锈钢SS304
阀 杆：不锈钢2Cr13
阀杆密封：FPM
球体密封：碳化PTFE
手柄：DN15-DN200电镀碳钢、对于≥DN200，我们建议用手动齿轮
连接方式：法兰/焊接连接
适用场合：供暖系统、供热区域、工业管道等用途。
适应介质：水，热水。
