一、进口天然气焊接球阀概述

进口天然气焊接球阀（美国威盾VTON），Gas welded ball valve，也叫天然气全焊接球阀，天然气放散球阀，天然气直埋式球阀，燃气埋地式球阀，是指专用于天然气管道，用来控制天然气的开启和关闭的全焊接球阀，采用20号钢作为阀体，由钢管焊接而成，球垫采用强化聚四氟乙烯，用于天然气管道开关截止的球阀。阀杆采用防爆设计。温度范围：-60-200℃。全焊接球阀广泛应用于天然气、石油、供热、化工及热电管网等长输管线领域。

Gas welded ball valve (VTON), also known as natural gas fully welded ball valve, natural gas release ball valve, natural gas buried ball valve, and gas buried ball valve, refers to a fully welded ball valve specially designed for natural gas pipelines to control the opening and closing of natural gas. It uses 20 # steel as the valve body and is welded from steel pipes. The ball pad is made of reinforced polytetrafluoroethylene, and is used for the opening and closing of natural gas pipelines. The valve stem adopts explosion-proof design. Temperature range: -60-200 ℃. Fully welded ball valves are widely used in long-distance pipeline fields such as natural gas, oil, heating, chemical, and thermal power pipelines.

二、进口天然气焊接球阀产品特点

1、钢制球阀，带有轴向负载的焊接端
2、不需要维护，调整及润滑，易于安装，在低运行费用下长期可靠运行；
3、阀杆可以加长、易于保温；
4、操作手柄可以拆下，换向安装；
5、阀体不含沉重且不可靠的铸件；
6、安装调节机构，非常简便；

7、一体式焊接球阀、不会有外部泄露等现象，适用于天然气管线。

1. Steel ball valve, welded end with axial load

2. No maintenance, adjustment, or lubrication required, easy to install, and reliable long-term operation at low operating costs;

3. The valve stem can be extended and easily insulated;

4. The operating handle can be removed and installed in reverse;

5. The valve body does not contain heavy and unreliable castings;

6. Installing the adjustment mechanism is very simple;

7. Integrated welded ball valve, without external leakage and other phenomena, suitable for natural gas pipelines.

三、进口天然气焊接球阀产品参数：
压力等级：1.6MPa~ 4.0MPa
产品规格：DN15 ~ 1000mm
产品材质：ST37.8，锻钢A105
适用温度：-29℃≤t≤150 ℃（跟阀体材质及密封面材质不同所承温有差异）
驱动方式：气动、电动、手动、蜗轮驱动等
阀体材质：铸钢、不锈钢、锻钢
阀 体：钢制Q235A
球 体：不锈钢SS304
阀 杆：不锈钢2Cr13
阀杆密封：FPM
球体密封：碳化PTFE
手柄：DN15-DN200电镀碳钢、对于≥DN200，我们建议用手动齿轮
连接方式：法兰/焊接连接
适用场合：供暖系统、供热区域、工业管道等用途。
适应介质：燃气、天然气、煤气。
