一、进口卫生级三通球阀概述

进口卫生级三通球阀（美国威盾VTON），sanitary three-way ball valve，也叫卫生级T型三通球阀，卫生级L型三通球阀，卡箍式三通球阀，快装三通球阀，是指球阀采用经过抛光和灭菌处理，达到卫生级要求，球体有三个通孔，分为T型和L型结构，可以对介质进行分流、合流或者换向的卫生级球阀。

美国威盾VTON卫生级三通球阀可以满足食品、生物制药领域各种介质的特殊要求，其光滑、无缝、自动排空手工艺流体通道还非常适用于蒸汽踏它就地清洗的需要，在制造加工过程中严格按FDA要求进行质量临控，采用电脑三维设计，是为GMP要求而制造的。

Sanitary three-way ball valve (VTON,), also known as sanitary T-shaped three-way ball valve, sanitary L-shaped three-way ball valve, clamp type three-way ball valve, and quick installation three-way ball valve, refers to a sanitary grade ball valve that has been polished and sterilized to meet sanitary requirements. The ball has three through holes and is divided into T-shaped and L-shaped structures, which can separate, merge, or reverse the medium.

The American Weidun VTON sanitary three-way ball valve can meet the special requirements of various media in the food and biopharmaceutical fields. Its smooth, seamless, automatic emptying process fluid channel is also very suitable for on-site cleaning of steam pedals. During the manufacturing process, quality control is strictly carried out in accordance with FDA requirements, and computer 3D design is adopted. It is manufactured for GMP requirements.

二、进口卫生级三通球阀产品特点

1、孔径大小与管道一致，不产生沉淀物

2、流道内壁240Grit抛光，保证流道畅通无阻

3、采用全包的PTFE密封没有死角，易清洗

4、双层阀杆填料与对压碟型弹片装置

1. The aperture size is consistent with the pipeline and does not produce sediment.

2. The inner wall of the flow channel is polished with 240Grit to ensure smooth and unobstructed flow.

3. Adopting a fully enclosed PTFE seal with no dead corners, easy to clean.

4. Double layer valve stem packing and pressure disc type spring device.

三、进口卫生级三通球阀参数

尺寸规格：DIN标准(DN10-DN150),3A/IDF标准(1/2"-6"),ISO标准(Ф12.7-Ф152.4)

标准：DIN,ISO,SMS,3A,IDF等

连接:卡箍(卡箍)式、对焊(焊接)式、螺纹(活接)式
材质：不锈钢304,316,304L,316L
壁厚：SCH5S-SCH160S
适用温度：-20~232℃
适用介质：水、油、气及某些腐蚀液体
特点：外形美观，表面平整，耐酸碱，抗防腐，质感性能强
工作压力：1.0Mpa
工作温度：—10℃+150℃
范围：食品、饮料、制药、乳制品、啤酒以及精细化

四、进口卫生级三通球阀流向尺寸图
