一、进口电动卫生级球阀概述

进口电动卫生级球阀（美国威盾VTON），Electric sanitary ball valve，也叫电动卫生球阀，电动卫生级快装球阀，电动不锈钢316L球阀，是指用电动执行器和不锈钢卫生级球阀组成，由电动执行器控制球阀开关的装置。

美国威盾VTON电动卫生级球阀皆经过了精密的检验流程和严格的品质管理，流道经过精密抛光和除菌处理。阀体采用不锈钢精制而成，流道内壁0.5um（240Grit）电子抛光，保持流体畅通无阻。密封面采用的全包PTFE没有死角，保证卫生且容易清洗。两端为卡箍连接方便拆卸、清洗、维修。广泛应用于啤酒工程、食品工程、化学工程、制药工程、生物工程和水处理工程等领域。

Electric sanitary ball valve (VTON), also known as electric sanitary ball valve, electric sanitary quick fit ball valve, electric stainless steel 316L ball valve, refers to a device composed of an electric actuator and a stainless steel sanitary ball valve, which is controlled by an electric actuator to open and close the ball valve.

The American Weidun VTON electric sanitary grade ball valves have undergone precise inspection processes and strict quality management, and the flow channels have undergone precision polishing and sterilization treatment. The valve body is made of refined stainless steel, and the inner wall of the flow channel is electropolished with a thickness of 0.5um (240Grit) to ensure unobstructed fluid flow. The sealing surface is made of fully wrapped PTFE without dead corners, ensuring hygiene and easy cleaning. The two ends are connected with clamps for easy disassembly, cleaning, and maintenance. Widely used in fields such as beer engineering, food engineering, chemical engineering, pharmaceutical engineering, biotechnology, and water treatment engineering.

二、进口电动卫生级球阀产品特点

1、电动卫生级球阀孔径大小与管道一致，不产生沉淀物。

2、电动卫生级球阀流道内壁240Grit抛光，保证流道畅通无阻。

3、电动卫生级球阀采用全包的PTFE密封没有死角，易清洗。

1. The aperture size of the electric sanitary ball valve is consistent with that of the pipeline and does not produce sediment.

2. The inner wall of the flow passage of the electric sanitary grade ball valve is polished with 240Grit to ensure smooth and unobstructed flow passage.

3. The electric sanitary grade ball valve adopts a fully enclosed PTFE seal with no dead corners and is easy to clean.

三、进口电动卫生级球阀产品参数

电源：AC110、220、380V/DC24、220V

公称通径：15～102mm

输出力矩：50N·M～2000N·M

公称压力：PN1.0MPa

任选功能：开关型、触点型、开度信号、智能调节型

阀轴材质：不锈钢

动作范围：0～90°±5°

阀体材质：304/316/316L不锈钢

动作时间：15秒/30秒/60秒

球体材质：304/316/316L不锈钢

环境温度：-30°～60° 阀座密封 PTFE

手动操作：附带手柄操作

温度：PTFE≤180℃

限位：电气、机械二重限位

结构型式：卡箍式、焊接式、螺纹式

防护等级：IP-67(防爆外壳:Exd Ⅱ BT4 IP67可选)

适用介质：啤酒、葡萄酒、生物工程、食品、制药、饮料、乳品等

输入信号：0-10，1-5VDC/4-20mA(智能调节型)

特点：安全卫生，密封好、使用寿命长
