一、进口气动卫生级快装球阀概述

进口气动卫生级快装球阀（美国威盾VTON），Pneumatic sanitary quick ball valve，也叫气动快装球阀，气动卡箍球阀，气动卫生级球阀，气动316L球阀，是指由气动执行器和快装的卫生级球阀组成。有气源推动执行器对球阀进行远程智能控制开关的装置。

进口气动卫生级快装球阀皆经过精密的检验流程和严格的品质管理。加工过程中，流道经过精密抛光和灭菌处理。其结构是由三部分阀壳组成，由外部四只较长螺栓从两端夹住中间阀体与阀球而成。密封圈为全封闭式紧紧包裹住阀球，无空间和死角。两端为卡箍连接方便拆卸、清洗、维修工作原理也是通过气动执行器90度的旋转来带动球体的旋转以达到介质的流通与阻断。广泛应用于食品、饮料、乳品、制药、酿造、啤酒、化工、石油。

Pneumatic sanitary quick ball valve (VTON), also known as pneumatic quick ball valve, pneumatic clamp ball valve, pneumatic sanitary ball valve, and pneumatic 316L ball valve, refers to a sanitary ball valve composed of a pneumatic actuator and quick installation. A device that remotely intelligently controls the opening and closing of a ball valve by pushing the actuator with an air source.

Pneumatic sanitary level quick acting ball valves have undergone precise inspection processes and strict quality management. During the processing, the flow channel undergoes precision polishing and sterilization treatment. Its structure is composed of three parts of the valve shell, which is formed by four longer external bolts clamping the middle valve body and valve ball from both ends. The sealing ring is fully enclosed and tightly wraps around the valve ball, without any space or dead corners. The two ends are connected with clamps for easy disassembly, cleaning, and maintenance. The working principle is also to drive the rotation of the sphere through the 90 degree rotation of the pneumatic actuator to achieve the flow and blockage of the medium. Widely used in food, beverages, dairy products, pharmaceuticals, brewing, beer, chemicals, and petroleum.

二、进口气动卫生级快装球阀产品特点

气动卫生级快装球阀孔径大小与管道一致，不产生沉淀物
气动卫生级快装球阀流道内壁240Grit抛光，保证流道畅通无阻
气动卫生级快装球阀采用全包的PTFE密封没有死角，易清洗
气动卫生级快装球阀双层阀杆填料与对压碟型弹片装置

气动卫生级快装球阀反应灵敏迅速，智能化控制

The aperture size of the pneumatic sanitary quick installation ball valve is consistent with that of the pipeline and does not produce sediment

The inner wall of the flow passage of the pneumatic sanitary grade quick installation ball valve is polished with 240Grit to ensure smooth and unobstructed flow passage

The pneumatic sanitary grade quick installation ball valve adopts a fully enclosed PTFE seal without dead corners, making it easy to clean

Double layer valve stem packing and counter pressure disc type shrapnel device for pneumatic sanitary level quick installation ball valve

Pneumatic sanitary grade quick installation ball valve with sensitive and rapid response, intelligent control

三、进口气动卫生级快装球阀参数
