一、进口卫生级316L球阀概述

进口卫生级316L球阀（美国威盾VTON），Sanitary 316L ball valve，也叫不锈钢316L球阀，316L快装球阀，316L卡箍球阀，是指阀体采用抛光度达到卫生级标准的不锈钢316L制作的球阀，可以满足食品、生物制药领域各种介质的特殊要求，其光滑、无缝、自动排空手工艺流体通道还非常适用于蒸汽踏它就地清洗的需要，在制造加工过程中严格按FDA要求进行质量临控，采用电脑三维设计，是为GMP要求而制造的。

Sanitary 316L ball valve (VTON, USA), also known as stainless steel 316L ball valve, 316L quick fit ball valve, 316L clamp ball valve, refers to a ball valve made of stainless steel 316L with a polishing degree that meets hygiene standards. It can meet the special requirements of various media in the food and biopharmaceutical fields. Its smooth, seamless, and automatic emptying process fluid channel is also very suitable for on-site cleaning by steam tapping. Quality control is strictly carried out in the manufacturing process according to FDA requirements, and computer 3D design is used. It is manufactured for GMP requirements.

二、进口卫生级316L球阀产品特点

1、卫生级316L球阀流体阻力少，无论是缩径或全通径球阀流阻系数都是所有阀类当中最小的。
2、卫生级316L球阀开关迅速方便，一般情况下只需要手柄转动90℃就完成全开或全关动作，真正实现快速启闭。
3、卫生级316L球阀密封性能好，绝大多数球阀阀座都采用聚四氟乙烯等弹性材料制造，一般这种软密封的密封性容易保证，所有广泛使用。
4、寿命长，由于聚四氟乙烯有良好的自润滑性，与阀体球体阀杆的摩擦磨损小，所有大大提高了球阀的使用寿命。
5、可靠性高，球体与阀座不会擦伤，急剧磨损阀杆不会飞出，有防火、防静电功能。
6、卫生级316L球阀使用广泛，除一般介质外，还可输送粘性流体、浆液以及固体颗粒。
7、多种转动方式，轻易实现远距离操作以及自动化控制需要。
8、体积小，可安装于管路任一位置，安装快捷方便，运输贮藏也很容易。

1. The sanitary grade 316L ball valve has low fluid resistance, and the flow resistance coefficient of both reduced and full bore ball valves is the smallest among all valve types.

2. The sanitary grade 316L ball valve switch is fast and convenient. Generally, only the handle needs to be rotated 90 ℃ to complete the full open or full close action, truly achieving fast opening and closing.

3. The sanitary grade 316L ball valve has good sealing performance, and the vast majority of ball valve seats are made of elastic materials such as polytetrafluoroethylene. Generally, the sealing performance of this soft seal is easy to ensure, and it is widely used.

4. Long service life, due to the good self-lubricating property of polytetrafluoroethylene, the friction and wear with the valve body and valve stem are small, greatly improving the service life of the ball valve.

5. High reliability, the ball and valve seat will not be scratched, and the valve stem will not fly out due to sharp wear. It has fire and anti-static functions.

6. Sanitary grade 316L ball valves are widely used and can transport viscous fluids, slurries, and solid particles in addition to general media.

7. Multiple rotation modes, easy to achieve remote operation and automation control needs.

8. Small in size, can be installed at any position in the pipeline, fast and convenient to install, and easy to transport and store.

三、进口卫生级316L球阀产品参数

1、原料：304材质和316L材质两种常用材料，产品与介质接触部分304或316L

2、密封件：有较强的耐酸、碱和耐高温性能 永久压缩变形小

3、连接：焊接式 快装式 螺纹式

4、质量：产品内外用高档抛光设备处理，达到表面精密度要求

5、精度：严格按照3A、DIN、SMS、BS等产品公差标准执行.

6、工作压力：1.0Mpa

7、工作温度：—10℃+150℃

8、密封材料：标本EPDM，另有硅胶、氟胶可选用

9、适用介质：液体、气体、油品、各种高腐蚀化学介质

四、进口卫生级316L球阀尺寸图
