一、进口三片式卡箍球阀概述

进口三片式卡箍球阀（美国威盾VTON），Three - piece clamp Sanitary ball valve，也叫三片式快装球阀，三段式快装球阀，三段式卡箍球阀，是指采用卡箍快装的连接方式，不锈钢304或者316L作为阀体材质的三片式球阀。广泛应用范围： 食品、饮料、制药、乳制品、啤酒以及精细化工的管道介质的开启和关闭。

Three piece clamp Sanitary ball valve (VTON), also known as three piece quick fit ball valve, three-piece quick fit ball valve, three-piece clamp ball valve, refers to a three piece ball valve that uses a clamp quick fit connection method, with stainless steel 304 or 316L as the valve body material. Widely applicable: opening and closing of pipeline media in food, beverages, pharmaceuticals, dairy products, beer, and fine chemicals.

二、进口三片式卡箍球阀产品特点

1、卡箍球阀的连接操作是非常简易，无需特殊的专业技能，普通工人经过简单的培训即可操作。

2、卡箍球阀操作简单，所需要的操作空间变小，这为日后的维修带来了许多方便条件。

3、维修和更换时，只需松开两片卡箍即可任意更找、转动、修改一段管道。不需破坏周围墙体，减少了维修时间和维修费用。

1. The connection operation of clamp ball valve is very simple, without the need for special professional skills. Ordinary workers can operate it after simple training.

2. The clamp ball valve is easy to operate and requires less operating space, which brings many convenient conditions for future maintenance.

3. When repairing and replacing, simply loosen the two clamps to freely locate, rotate, and modify a section of the pipeline. No need to damage the surrounding walls, reducing maintenance time and costs.

三、进口三片式卡箍球阀参数

规 格 DN15——DN150、1〞— 6〞Ф12.7—Ф152.4
连 接： 卡箍
标 准： ISO、DIN、IDF、SMS、3A等
材 质： 不锈钢sus304和sus316L
工业标准有：ISO,DIN,IDF,3A等
质 量： 产品内外用高档抛光设备处理，达到表面精密度要求
密 封 圈： EPDM、NBR、PTFE
包 装： 纸箱/木箱包装/塑料
工作压力： 1.0Mpa
工作温度： —10℃+150℃
应用范围： 食品、饮料、制药、乳制品、啤酒以及精细化工

四、进口三片式卡箍球阀尺寸图
